Notes
1 Indicator Stem - Visual 102143+
1a Indicator Stem - WCB 2-piece Control Top 118938+
1b Indicator Stem - Bürkert 8681 Control Top 131069+ 2
1c Indicator Stem - CU4 control Top 130390+ 2
1d Indicator Stem - Set and forget 119677+ 3
2 Stem, Upper 102142+
3 Stem, Lower 114394+
4 Cylinder 114388+
* 5 Bearing 102757+
* 6 O-ring Nitrile N70219
* 7 O-ring, Cylinder Nitrile N70240
* 8 Seal, U-cup 57-15
9 Cap Screw, 1/4-20 x .375" lg. 30-68
10 Piston & Spring Assembly 118144+ 5
* 11 O-ring Nitrile N70210
12 Yoke 114387+
13 Vent Plug 3023957+
* 14 Bearing, Piston 101995+
15 Piston, Lower 114391+
* 20 O-ring, Lower Piston Nitrile N70342
21 Stem, Outer 114393+
Actuator Seal Kit (contains recomm. spares)
134421+
4" Diamete
Notes
Air-to-Raise Visual Indicator Stem ACT00127 2
Control Top Indicator Stem ACT00254 3
PL5027-CH29
Part Description
Part Description
Complete Actuator Assemblies
4" Air-to-Raise 3-Position Actuator
Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 75
Notes
* Recommended Spare Parts
2. Stem only - does not include target
3. Stem for use with WCB 2-piece control top
5. SPX FLOW does not recommend any attempt at disassembly or repla
cement of the spring in the piston assembly –
please replace the entire caged piston & spring assembly when necessary.
