Item #
4" Diamete
r
Notes
1 Stop, Adjustable (Upper) 45417+
3 Stem, Lower 105793+
4 Cylinder 105794+
* 5 Bearing, Yoke 102757+
* 6 O-ring Nitrile N70210
* 7 O-ring, Cylinder Nitrile N70240
* 8 Seal, U-cup - Main Piston 57-15
9 Cap Screw, 1/4-20 x .375" lg. 30-68
10 Piston & Spring Assembly 118144+
* 11 O-ring Nitrile N70115
12 Yoke 102137+
13 Vent Plug 3023957+
15 Piston, Upper 70162+ 5
16 Cap Screw, 7/16-14 x 1.5" 30-332
* 17 Seal, U-cup - Upper Piston 57-11
18 Washer 3023961+
19 Lock Washer 9570210+
21 Hex Jam Nut 36-79
Actuator Seal Kit (contains recomm. spares)
134422+
105792+
PL5027-CH31
Part Description
Air-to-Lower
Complete Actuator Assemblies
4" Air-to-Lower 3-Position Actuator
Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 77
Notes
* Recommended Spare Parts
5. SPX FLOW does not recommend any attempt at disassembly or repla
cement of the spring in the piston assembly –
please replace the entire caged piston & spring assembly when necessary.
