11
A.0100.301 – IM-FIP/08.00 EN (02/2014)
6. Shaft
Bronze
0 = Splines – Stainless steel
Stainless steel pumps
0 = Splines – Stainless steel
2 = Double flat – Stainless steel
7. Shaft seals
M = Single mechanical seal
L = Lip seal
Material of single mechanical seals
01 = Carbon/ceramic/nitrile
03 = Silicon carbide/silicon carbide/FPM (DIN/ISO) / FKM (ASTM)
(on request only)
06 = FDA Approved mechanical seal
8. Shaft end
P = Pedestal
F = Flange for IEC motor
80 = FIP 20/25 – Pedestal; shaft height, mm
Flange; IEC motor size
90 = FIP 40 – Pedestal; shaft height, mm
Flange; IEC motor size
100 = FIP 50 – Pedestal; shaft height, mm
Flange; IEC motor size
112 = FIP 65 – Pedestal only; shaft height, mm
Example: FIP 20 SH – DIN 4 2 M01 P80
1 2 3 4 5 6 7 8
