10
A.0100.301 – IM-FIP/08.00 EN (02/2014)
1.5 Model Specifications
Example: FIP 20 SH – DIN 4 2 M01 P80
1 2 3 4 5 6 7 8
1. Family name
FIP = Flexible Impeller Pump
2. Pump size
20 =
25 =
40 = Average inlet and outlet port diameter, mm
50 =
65 =
See dimensional drawings, section 6.0
3. Material of pump body and cover
SH = Stainless steel, hygienic version
SI = Stainless steel, industrial version
B = Bronze
4. Port/connection
FIP 20/25SI, FIP 25/40B
BSP = BSP thread/hose combination
NPTF = NPTF thread/hose combination
FIP 40/50/65SI
BSP = BSP thread
NPTF = NPTF thread
FIP 20/25/40/50/65SH
DIN = DIN 11851
SMS = SMS 1145
PLN = Plain without threaded ports
CLP = Clamp according to SMS 3017 (TriClamp)
5. Impeller code
0 = Neoprene industrial version – standard pressure
3 = EPDM, FDA, food grade – high pressure
4 = Neoprene, FDA, milk grade
6 = Neoprene, industrial version – high/intermediate pressure
7 = EPDM, FDA, food grade – standard pressure
9 = Nitrile, splined drive – standard pressure
}
