5.8 Spare part list
FIP20S, FIP25S, FIP40S, FIP50S, FIP65S – Pedestal mounted
Drawing: Page 30
*) See key to model specification system, chapter 1.5.
Pos Nos Description Version *)
FIP20SI/SH
10-24544 SI
10-24543 SH
FIP25SI/SH
10-24546 SI
10-24545 SH
FIP40SI/SH
10-24548 SI
10-24547 SH
FIP50SI/SH
10-13219 SI
10-13217 SH
FIP65SI/SH
10-13220 SI
10-13221 SH
1 2 Cap screw (cover) 01-46505 01-46505 01-46505 01-46505 0.0195.200
2 1 Cover SI SI 01-35817 01-35818 01-35822 01-24532 01-24533
1 Cover SH SH 01-35849 01-35850 01-35851 01-24549 01-24550
3 1 Impeller - Neoprene 0 – – 09-838S 09-803S 09-815S
1 Impeller - Neoprene,
high pressure
6 – 09-837S – 09-809S –
1 Impeller - FDA, Neoprene 4 09-833S-4 09-837S-4 09-835S-4 09-809S-4 –
1 Impeller - FDA, EPDM 7 09-832S-7 09-836S-7 – – 09-840S-7
1 Impeller - FDA, EPDM,
high pressure
3 09-833S-7 – 09-835S-7 – –
1 Impeller - Nitrile, splined 9 09-1028S-9 – 09-1029S-9 – –
4 1 Pump body - BSP SI SI-BSP 01-24525-3 01-24527-3 01-24529-3 01-13190 01-13192
1 Pump body - NPTF SI SI-NPTF 01-24525-5 01-24527-5 01-24529-5 01-13190-4 01-13192-4
1 Pump body - Plain SH SH-PLN 01-24526-3 01-24528-3 01-24530-3 01-13191 01-13193
1 Pump body - SMS SH SH-SMS 09-46687-02 09-46687-06 09-46687-10 09-46687-13 09-46687-15
1 Pump body - DIN SH SH-DIN 09-46687-04 09-46687-08 09-46687-12 09-46687-14 09-46687-16
1 Pump body - CLP SH SH-CLP 01-24774-3 01-24775-3 01-24776-3 01-24777 01-24778
5 1 Mechanical seal SI
Carbon/Ceramic/Nitrile
M01 09-46686-01 09-46686-01 09-46686-05 09-46686-05 09-46686-09
1 Mechanical seal SH FDA
Carbon/Ceramic/EPDM
M06 09-46686-
03
09-46686-03 09-46686-07 09-46686-07 09-46686-10
5a 1 Washer Pedestal 01-46632 01-46632 01-45692 01-45692 01-46631
6 1 Pedestal Pedestal 01-24248 01-24248 01-24249 01-24012 01-13204
7 1 Shaft 2 01-35835 01-35836 01-35837 01-32609 01-35840
8 2 Screw stud Pedestal 01-46637 01-46639 01-46641 01-46642 01-46643
9 1 O-ring - Nitrile (cover) SI SI 0.2173.446 0.2172.013 0.2173.441 0.2173.437 0.2173.467
1 O-ring - FDA (cover) SH SH 0.2174.100 0.2173.523 0.2174.105 0.2174.110 0.2174.111
12 1 Retainer Pedestal 01-46632 01-46632 01-45692 01-45692 01-46631
13 1 Retaining ring Pedestal 0.0370.516 0.0370.516 0.0370.525 – –
14 1 Lip seal Pedestal 0.2233.014 0.2233.014 0.2233.008 0.2234.002 0.2234.012
15 2 Nut Pedestal 0.0195.100 0.0195.100 0.0195.100 0.0195.100 0.0195.200
16 2 Ball bearing Pedestal 0.3431.778 0.3431.778 0.3431.001 0.3431.488 0.3431.741
1 Roller bearing Pedestal – – – 0.3428.570 0.3428.570
17 1 Retaining ring Pedestal 0.0370.516 0.0370.516 0.0370.525 0.0370.040 0.0370.040
18 1 Spacer Pedestal 01-42583 01-42583 01-42747 01-45005 01-46656
19 1 Retaining ring Pedestal 0.0371.047 0.0371.047 0.0371.052 0.0371.080 0.0371.090
20 1 Lip seal Pedestal 0.2234.004 0.2234.004 0.2233.013 0.2234.003 0.2233.201
21 1 Lip seal retainer Pedestal – – – – 01-46902
22 1 Lip seal set Pedestal – – – – 09-46688-04
23 1 Screw Pedestal – – – – 0.0279.300
32 1 Key Pedestal – – 0.0502.231 0.0502.03 0.0502.038
