29
A.0100.301 – IM-FIP/08.00 EN (02/2014)
Pos Nos Description Version *)
FIP20SI/SH
10-13211 SI
10-13210 SH
FIP25SI/SH
10-13212 SI
10-13213 SH
FIP40SI/SH
10-13214 SI
10-13215 SH
FIP50SI/SH
10-13218 SI
10-13216 SH
1 2 Cap screw (cover) 01-46505 01-46505 01-46505 01-46505
2 1 Cover SI SI 01-35817 01-35818 01-35822 01-24532
1 Cover SH SH 01-35849 01-35850 01-35851 01-24549
3 1 Impeller - Neoprene 0 09-838S 09-803S
1 Impeller - Neoprene, high
pressure
6 09-837S 09-809S
1 Impeller - FDA, Neoprene 4 09-833S-4 09-837S-4 09-835S-4 09-809S-4
1 Impeller - FDA, EPDM 7 09-832S-7 09-836S-7
1 Impeller - FDA, EPDM
high pressure
3 09-833S-7 09-835S-7
1 Impeller - Nitrile, splined 9 09-1028S-9 09-1029S-9
4 1 Pump body - BSP SI SI-BSP 01-24525-1 01-24527-1 01-24529-1 01-13190
1 Pump body - NPTF SI SI-NPTF 01-24525-4 01-24527-4 01-24529-4 01-13190-4
1 Pump body - Plain SH SH-PLN 01-24526-1 01-24528-1 01-24530-1 01-13191
1 Pump body - SMS SH SH-SMS 09-46687-01 09-46687-05 09-46687-09 09-46687-13
1 Pump body - DIN SH SH-DIN 09-46687-03 09-46687-07 09-46687-11 09-46687-14
1 Pump body - CLP SH SH-CLP 01-24774-1 01-24775-1 01-24776-1 01-24777
5 1 Mechanical seal SI
Carbon/Ceramic/Nitrile
M01 09-46686-02 09-46686-02 09-46686-06 09-46686-05
1 Mechanical seal SH FDA
Carbon/Ceramic/EPDM
M06 09-46686-04 09-46686-04 09-46686-08 09-46686-07
6 1 Motor flange Flange 01-24252 01-24252 01-24255 01-24079
7 1 Shaft 2 01-46633 01-46634 01-46635 01-35040
8 2 Screw stud Flange 01-46636 01-46638 01-46640 01-46642
9 1 O-ring - Nitrile (cover) SI SI 0.2173.446 0.2172.013 0.2173.441 0.2173.437
1 O-ring - FDA (cover) SH SH 0.2174.100 0.2173.523 0.2174.105 0.2174.110
10 2 Screw Flange 0.0141.911 0.0141.911 0.0257.036 0.0141.918
11 4 Washer Flange 0.0350.116 0.0350.116 01-45767 0.0350.118
12 4 Screw Flange 0.0150.001 0.0150.001 0.0278.802
13 1 Washer Flange 01-45782 01-45782 01-45768 01-45692
14 4 Lock screw Flange 0.0300.943 0.0300.943 0.0300.943 0.0300.943
15 1 Sleeve Flange 01-45214 01-45214
16 1 Lip seal set Flange 09-46688-01 09-46688-01 09-46688-03 09-46688-01
17 1 Lip seal retainer Flange 01-46900 01-46900 01-46901 01-46900
5.6 Spare part list
FIP20S, FIP25S, FIP40S, FIP50S – Flange mounted
Drawing: Page 28
*) See key to model specification system, chapter 1.5.
