27
A.0100.301 – IM-FIP/08.00 EN (02/2014)
5.4 Spare part list
FIP25B and FIP40B – Pedestal mounted
Drawing: Page 26
*) See key to model specification system, chapter 1.5
Pos Nos Description Version*)
FIP25B
10-45875
FIP40B
10-45881
1 2 Cap screw (front cover) 01-46505 01-46505
2 1 Front cover 01-45781 01-45778
3 1 Impeller - Neoprene 0 09-1028B 09-819B
1 Impeller - Neoprene, high pressure 6 09-816B 09-818B
1 Impeller - Nitrile 9 09-1028B-9 09-819B-9
4 1 Pump body - BSP 01-24250-1 (1") 01-24251-1 (1.1/2")
1 Pump body - NPTF 01-24250-2 (1") 01-24251-2 (1.1/2")
5 1
Mechanical seal (SS-shaft)
Carbon/Ceramic/Nitrile
M01 09-45860-02 09-45860-14
6 1 Pedestal Pedestal 01-24248 01-24249
7 1 Shaft (SS) 01-35072 01-35041
8 2 Screw stud 01-45784 01-45770
9 1 O-ring - Nitrile (front cover) 0.2172.024 0.2173.459
1
O-ring - FPM (DIN/ISO) / FKM (ASTM)
(front cover)
0.2172.023
13 1 Retaining ring Pedestal 0.0370.516 0.0370.525
14 1 Lip seal Pedestal 0.2233.014 0.2233.008
15 2 Nut Pedestal 0.0195.100 0.0195.100
16 1 Ball bearing Pedestal 0.3431.778 0.3431.001
17 1 Retaining ring Pedestal 0.0370.516 0.0370.525
18 1 Spacer Pedestal 01-42583 01-42747
19 1 Retaining ring Pedestal 0.0371.047 0.0371.052
20 1 Lip seal Pedestal 0.2234.004 0.2233.013
21 1 Cam - 1/1 01-42679 01-45771
1 Cam - 1/2 01-42584
1 Cam - 2/3 01-42442
22 1 Wear plate 01-42443 01-42423
23 1 Pin 01-42400 01-42426
24 1 Cam screw - 1/1 01-46794-01 01-46794-02
1 Cam screw - 1/2 01-46794-06
1 Cam screw - 2/3 01-46794-07
32 1 Key Pedestal 0.0502.231
