5.2 Spare part list
FIP25B and FIP40B – Flange mounted
Drawing: Page 24
*) See key to model specification system, chapter 1.5
Pos Nos Description Version*)
FIP25B
10-45874
FIP40B
10-45880
1 2 Cap screw (front cover) 01-46505 01-46505
2 1 Front cover 01-45781 01-45778
3 1 Impeller - Neoprene 0 09-1028B 09-819B
1 Impeller - Neoprene, high pressure 6 – –
1 Impeller - Nitrile 9 09-1028B-9 09-819B-9
4 1 Pump body - BSP 01-24250-1 (1") 01-24251-1 (1.1/2")
1 Pump body - NPTF 01-24250-2 (1") 01-24251-2 (1.1/2")
5 1
Mechanical seal (SS-shaft)
Carbon/Ceramic/Nitrile
M01 09-45860-01 09-45860-13
6 1 Motor flange Flange 01-24252 01-24255
7 1 Shaft (SS) 01-45780 01-45766
8 2 Screw stud 01-45779 01-45765
9 1 O-ring - Nitrile (front cover) 0.2172.024 0.2173.459
21 1 Cam - 1/1 01-42679 01-45771
1 Cam - 1/2 01-42584 –
1 Cam - 2/3 01-42442 –
22 1 Wear plate 01-42443 01-42423
23 1 Pin 01-42400 01-42426
24 1 Cam screw - 1/1 01-46794-01 01-46794-02
1 Cam screw - 1/2 01-46794-06 –
1 Cam screw - 2/3 01-46794-07 –
26 2 Screw Flange 0.0141.911 0.0257.036
27 4 Washer Flange 0.0350.116 01-45767
28 4 Screw Flange 0.0150.001 0.0278.802
29 1 Washer Flange 01-45782 01-45768
30 4 Lock screw Flange 0.0300.943 0.0300.943
31 1 Sleeve Flange 01-45214 –
