SPX FIP - series User Manual

12
A.0100.301 – IM-FIP/08.00 EN (02/2014)
1.6 Impeller data
1.6.1 Pump sizes FIP20S – FIP65S
Hub material in all impellers = SS
Std = Standard pressure
IP = Intermediate pressure
HP = High pressure
Pump
size
Impeller
No
Hub type Impeller material
Impeller
code
Min. start
torque (Nm)
Min. reverse
torque (Nm)
Max. head
(bar)
Max
suction
lift dry (m)
FIP20S 832S-7 Double flat EPDM, FDA, Food 7 2.2 5.2 2.5 4.5
FIP20S 833S-4 Double flat Neoprene, FDA, Milk 4 2.2 5.2 2.5 4.5
FIP20S 833S-7 Double flat EPDM, FDA, Food HP 3 3.0 6.0 4.0 4.5
FIP25S 837S Double flat Neoprene HP 6 7. 2 12.0 4 5.0
FIP25S 836S-7 Double flat EPDM, FDA, Food 7 4.6 8.3 2.5 5.0
FIP25S 837S-4 Double flat Neoprene, FDA, Milk 4 7. 2 12.0 2.5 5.0
FIP25S 1028S-9 Splined Nitrile 9 4.6 8.3 1.75 4.0
FIP40S 835S-4 Double flat Neoprene, FDA, Milk 4 11.0 25.0 2.5 5.0
FIP40S 835S-7 Double flat EPDM, FDA Food HP 3 19.0 32.5 4 5.0
FIP40S 838S Double flat Neoprene Std 0 11.0 25.0 2.5 5.0
FIP40S 1029S-9 Splined Nitrile 9 8.8 25.0 1.75 4.0
FIP50S 803S Double flat Neoprene Std 0 19.6 36.4 1.3 4.0
FIP50S 809S Double flat Neoprene IP 6 22.2 42.0 1.8 5.0
FIP50S 809S-4 Double flat Neoprene, FDA, Milk 4 22.2 42.0 1.3 4.0
FIP65S 815S Double flat Neoprene Std 0 40.0 75.0 2.5 4.0
FIP65S 840S-7 Double flat EPDM, FDA, Food HP 7 30.3 65.0 2.5 4.0
1.6.2 Pump sizes FIP25B and FIP40B
Pump
size
Impeller
No
Hub
material
Hub
type
Impeller
material
Impeller
code
Min. start
torque
(Nm)
Min.
reverse
torque
(Nm)
Max. head
(bar)
Max suction
lift dry (m)
FIP25B 1028B Bronze Splined Neoprene Std 0 4.6 8.3 2.5 5.0
FIP25B 1028S SS Splined Neoprene Std 0 4.6 8.3 2.5 5.0
FIP25B 816B Bronze Splined Neoprene HP 6 7. 2 12.0 4.0 5.0
FIP25B 816S SS Splined Neoprene HP 6 7. 2 12.0 4.0 5.0
FIP25B 1028B-9 Bronze Splined Nitrile 9 4.6 8.3 1.75 4.0
FIP25B 1028S-9 SS Splined Nitrile 9 4.6 8.3 1.75 4.0
FIP40B 819B Bronze Splined Neoprene Std 0 11.0 25.0 2.5 5.0
FIP40B 1029S SS Splined Neoprene Std 0 8.8 25.0 2.5 5.0
FIP40B 818B Bronze Splined Neoprene HP 6 19.0 32.5 4.0 5.0
FIP40B 819B-9 Bronze Splined Nitrile 9 11.0 25.0 1.75 4.0
FIP40B 1029S-9 SS Splined Nitrile 9 8.8 25.0 1.75 4.0
Std = Standard pressure
IP = Intermediate pressure
HP = High pressure
