SRAM G2 RE User Manual

22
Caliper Piston Installation
Insert the compression fitting into the banjo and hold it firmly into the Insert the compression fitting into the banjo and hold it firmly into the
banjo. Thread the compression fitting into the banjo by hand until it banjo. Thread the compression fitting into the banjo by hand until it
stops.stops.
Tighten the compression nut and compression fitting to 8 N·m (71 in-lb).Tighten the compression nut and compression fitting to 8 N·m (71 in-lb).
Install a crowfoot socket at 90 degrees to the torque wrench to ensure Install a crowfoot socket at 90 degrees to the torque wrench to ensure
an accurate torque value.an accurate torque value.
Install the hose boot onto the compression nut.Install the hose boot onto the compression nut.
12
13
Flare nut crow foot 8 mm 8 N·m (71 in-lb)
14
