23
Caliper Piston Installation
Insert the bleed block into the caliper.Insert the bleed block into the caliper.
⚠ WARNING
You must bleed your brakes before reinstalling the brake pads.
Installing the brake pads prior to bleeding the brakes could
contaminate the brake pads and could lead to a brake failure.
Spray isopropyl alcohol on the caliper and clean it with a shop towel.Spray isopropyl alcohol on the caliper and clean it with a shop towel.
Visually check your work. If any of the o-rings protrude from the banjo fitting or banjo bolt, remove and replace the o-rings, then repeat the installation
process.
⚠ CAUTION
Servicing your brakes removes all of the fluid from the system. You must bleed the brakes after you service the brake caliper and/or lever.
For brake bleed, brake hose shortening, and brake pad replacement instructions, visit www.sram.com/service.
15
2011-2017 Code / Guide RE / G2 RE bleed block
16
