17Caliper Piston Installation
Remove the o-rings from the banjo bolt and banjo fitting.
Apply a small amount of DOT grease to the new o-rings and install
them.
Hold the banjo at the desired angle.
Tighten the banjo bolt to 5 N·m (44.2 in-lb).
Insert the bleed block into the caliper.
Install the pad retention bolt.
⚠ WARNING
You must bleed your brakes before reinstalling the brake pads.
Installing the brake pads prior to bleeding the brakes could
contaminate the brake pads and lead to a brake failure.
5
6
T25 5 N·m (44.2 in-lb) 22 mm
7
Bleed block 15 N•m (133 in-lb) 22 mm
8
