35Reservoir Cap Installation
Reservoir Cap Installation
Press the bladder into the reservoir cap, make sure the bladder is
properly seated into the reservoir cap. The bladder should be flush
with the cap.
Insert the reservoir cap/bladder assembly onto the lever body.
Install the detent ball followed by the detent spring into the lever body
reservoir hole closest to the lever blade.
Use a torque wrench and a T10 TORX bit socket to tighten each
reservoir cap bolt to 1.2 N·m (10.5 in-lb).
1
2
3
4
T10 1.2 N•m (10.5 in-lb) 22 mm
