34Lever Blade Installation
G2 Ultimate: Apply a small amount of Loctite Threadlocker Blue 242
onto each pivot bolt.
Use a torque wrench and a T10 TORX bit socket to tighten each pivot
bolt to 1.2 N·m (10.5 in-lb).
G2 RSC: Use a hammer to gently tap the pivot pin into the pivot hole.
3
G2 Ultimate Loctite Threadlocker Blue 242 15 N•m (133 in-lb) 22 mm
G2 Ultimate 1.2 N•m (10.5 in-lb) T10
