22Lever Fluid Removal
Remove the reservoir cap bolt nearest to the lever blade.
Carefully turn the lever body upside down so that the detent spring
and ball fall out of the lever body. If they do not initially fall out, gently
tap the lever against a clean shop towel.
Remove the remaining reservoir cap bolt.
Remove the reservoir cover and bladder from the lever body.
5
T10 15 N•m (133 in-lb) 22 mm
6
7
T10 15 N•m (133 in-lb) 22 mm
8
