SRAM HydroR - Brake Bleeding Procedures

10
Caliper Piston Removal
Caliper Piston Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Disconnect the hose from the banjo.
NOTICE
Fluid will drip. Place an oil pan and/or rag under the hose.
Install the caliper into the soft jaws of a vise. Remove the banjo bolt.
Set the banjo aside.
Remove the caliper body bolt.
Separate the caliper body halves.
1
6 and 9 mm Connectamajig™
8 and 10 mm Flat and Post mount
8 mm Post Mount
T25 Flat Mount
2
T25 Post Mount
T25 Flat Mount
3
4
