Master Cylinder Piston Removal
Master Cylinder Piston Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g. your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
There are two stop plate types for HydroR disc brakes: stop plate
generation 1, and stop plate generation 2. Follow the procedure for the stop
plate type in your lever assembly.
Remove the shifter cable from the derailleur cable anchor points
according to the user manual on www.sram.com/service, if applicable.
Remove the handlebar tape. Loosen the handlebar clamp and remove
the brake lever from the bicycle.
Remove the hood cover.
Use a pick to remove the circlip from the lever pivot pin.
