SRAM HydroR - Page 18

18
Master Cylinder Piston Removal
Push the pivot pin out of the lever blade. Remove the lever bias spring.
⚠ WARNING EYE HAZARD
Wear safety glasses. The lever bias spring may eject from the lever.
Turn the reach adjust pushrod clockwise to release the pivot barrel(s)
and lever blade from the hood. Use your hand to hold the shifter blade
out of the way on shift-brake models.
Set the lever blade assembly aside.
Fill a clean bleed syringe with 5-10 ml of DOT 5.1 brake fluid.
Remove the bleed screw from the bleed port.
4
Small hex wrench
5
2.5 mm Shift-brake lever
2.5 mm Brake lever
6
DOT 5.1 brake fluid 5-10 ml
7
T10 TORX®
