SRAM HydroR - Master Cylinder Piston Installation

22
Master Cylinder Piston Installation
Master Cylinder Piston Installation
Apply grease to the piston seal and o-rings on a new master cylinder
piston assembly.
Install the spring onto the white spring capture on the master
cylinder shaft.
Install the master cylinder assembly.
Install the reach adjust pushrod through the stop plate. Use your hand
to hold the shifter blade out of the way on shift-brake models.
1
DOT grease
2
Stop plate gen. 1
Stop plate gen. 2
3
