SRAM HydroR - Hose Removal

28
Hose Removal
Hose Removal
Remove the wheel from the bicycle according to the manufacturer's
instructions.
Remove the E-clip from the pad retention bolt.
Remove the pad retention bolt from the caliper.
Remove the brake pads.
NOTICE
Brake pads must be replaced if the total thickness of the backing plate
and pad friction material is less than 3 mm.
Insert the bleed block into the caliper, then install the pad
retention bolt.
1
2
Needle nose pliers
2.5 mm
3
Digital Caliper
2.5 mm
4
