PUSHLOC REMOTE SERVICE
CABLE REMOVAL
1
Push the remote lever until it returns toward you.
2
RLT: Use a 2 mm hex wrench to loosen the cable pinch bolt on the
spool and pull the cable out of the cable end slot. Use pliers to
remove the cable end.
RL: Use a 2 mm hex wrench to loosen the cable pinch bolt on the
spool. Use pliers to remove the cable end.
3
Disconnect the cable from the damper and pull the cable housing
o the cable.
4
Use a 2 mm hex wrench to open the cable hatch cover.
Push the cable through the remote until the cable head is far
enough out of the lever to access.
2 mm RLT
2 mm RL
2 mm
24
PUSHLOC™ REMOTE SERVICE
