4
RLT: Wrap the cable around the spool and insert it through the
cable fixing port. While firmly pulling the cable, use a 2 mm hex
wrench to tighten the cable pinch bolt to 0.9 Nm (8 in-lb).
Cut the excess cable, leaving 30 mm protruding from the cable
fixing port. Install a cable end fitting and tuck the cable end into
the slot in the spool.
RL: Wrap the cable around the spool. While firmly pulling the
cable, use a 2 mm hex wrench to tighten the cable pinch bolt to
0.9 Nm (8 in-lb).
Cut the excess cable and install a cable end fitting.
This concludes the service for RockShox Reba front suspension forks.
2 mm RLT
2 mm RL
26
CABLE INSTALLATION
