SR715/720 PARTS LIST
7-12
Miscellaneous and Chassis Assembly Parts List
REF.
SRS PART# VALUE DESCRIPTION
U 802 3-00449-342 27C256-120 EPROM/PROM, I.C.
Z 0 0-00079-031 4-40X3/16 M/F Standoff
Z 0 0-00187-021 4-40X1/4PP Screw, Panhead Phillips
Z 0 0-00351-029 4-40X1/4TRUSSPH Screw, Truss Phillips
Z 0 0-00400-026 4-40X7/8 PP Screw, Black, All Types
Z 0 0-00420-031 4-40X13/16 M/F Standoff
Z 0 0-00500-000 554808-1 Hardware, Misc.
Z 0 1-00174-171 18 COND DIL Cable Assembly, Ribbon
Z 0 1-00175-171 28 COND DIL Cable Assembly, Ribbon
Z 0 1-00177-171 30 CON DIL Cable Assembly, Ribbon
Z 0 7-00425-720 SR720-22 Fabricated Part
Option 1 Parts List
REF.
SRS PART# VALUE DESCRIPTION
0 1-00159-165 RS232 FEM BOOT Connector, D-Sub, Female
C 1501 5-00100-517 2.2U Capacitor, Tantalum, 35V, 20%, Rad
C 1502 5-00225-548 .1U AXIAL Capacitor, Ceramic, 50V,+80/-20% Z5U AX
C 1503 5-00225-548 .1U AXIAL Capacitor, Ceramic, 50V,+80/-20% Z5U AX
D 1501 3-00004-301 1N4148 Diode
D 1502 3-00004-301 1N4148 Diode
J 1501 1-00110-130 30 PIN DIL Connector, Male
J 1502 1-00160-162 IEEE488/STAND. Connector, IEEE488, Standard, R/A, Femal
J 1503 1-00158-159 RS232 25 PIN D Connector, D-Sub, Right Angle PC, Male
N 1501 4-00587-425 10KX7 Resistor Network SIP 1/4W 2% (Common)
PC1 7-00400-701 SR720 Printed Circuit Board
R 1501 0-00001-000 WIRE Hardware, Misc.
R 1502 0-00001-000 WIRE Hardware, Misc.
R 1503 4-00034-401 10K Resistor, Carbon Film, 1/4W, 5%
R 1504 4-00021-401 1.0K Resistor, Carbon Film, 1/4W, 5%
SW1501 2-00014-207 SPSTX8 Switch, DIP
U 1501 3-00401-340 74HCT244 Integrated Circuit (Thru-hole Pkg)
U 1502 3-00645-340 NAT9914APD Integrated Circuit (Thru-hole Pkg)
U 1503 3-00078-340 DS75160A Integrated Circuit (Thru-hole Pkg)
U 1504 3-00079-340 DS75161A Integrated Circuit (Thru-hole Pkg)
U 1505 3-00406-340 74HCT374 Integrated Circuit (Thru-hole Pkg)
U 1506 3-00406-340 74HCT374 Integrated Circuit (Thru-hole Pkg)
U 1507 3-00469-340 7406 Integrated Circuit (Thru-hole Pkg)
U 1508 3-00469-340 7406 Integrated Circuit (Thru-hole Pkg)
U 1509 3-00039-340 74HC14 Integrated Circuit (Thru-hole Pkg)
Z 0 0-00043-011 4-40 KEP Nut, Kep
Z 0 0-00079-031 4-40X3/16 M/F Standoff
Z 0 0-00438-021 4-40X5/16PP Screw, Panhead Phillips
