SRS Labs SR715 User Manual

PERFORMANCE TESTS
5-9
* 100 kHz measurements for SR720 only.
Resistance Accuracy
resistance range conditions Value Pass Fail
10.0 3 1 kHz series ____________ ____ ____
25.0 3 1 kHz series ____________ ____ ____
25.0 3 10 kHz series ____________ ____ ____
25.0 3 100 kHz series* ____________ ____ ____
100.0 3 1 kHz series ____________ ____ ____
100.0 2 1 kHz series ____________ ____ ____
400.0 2 1 kHz series ____________ ____ ____
400.0 2 10 kHz series ____________ ____ ____
400.0 2 100 kHz series* ____________ ____ ____
1.6000k 2 1 kHz parallel ____________ ____ ____
1.6000k 1 1 kHz parallel ____________ ____ ____
6.4000k 1 1 kHz parallel ____________ ____ ____
6.4000k 1 10 kHz parallel ____________ ____ ____
6.4000k 1 100 kHz parallel* ____________ ____ ____
25.0000k 1 1 kHz parallel ____________ ____ ____
25.0000k 0 1 kHz parallel ____________ ____ ____
100.0000k 0 1 kHz parallel ____________ ____ ____
100.0000k 0 10 kHz parallel= ____________ ____ ____
400.0000k 0 1 kHz parallel ____________ ____ ____
†
if the Q value is greater than 0.1, the allowed tolerance must be multiplied by (1+Q).
Capacitance Accuracy
capacitance Frequency Range Value Pass Fail
1.0n 1 kHz 0 ____________ ____ ____
1.0n 10 kHz 1 ____________ ____ ____
1.0n 100 kHz* 2 ____________ ____ ____
10.0n 100 Hz 0 ____________ ____ ____
10.0n 1 kHz 1 ____________ ____ ____
10.0n 10 kHz 2 ____________ ____ ____
10.0n 100 kHz* 2 ____________ ____ ____
100n 100 Hz 1 ____________ ____ ____
100n 1 kHz 2 ____________ ____ ____
100n 10 kHz 2 ____________ ____ ____
100n 100 kHz* 3 ____________ ____ ____
1.000µ 100 Hz 2 ____________ ____ ____
1.000µ 1 kHz 2 ____________ ____ ____
1.000µ 10 kHz 3 ____________ ____ ____
10.000µ 100 Hz 2 ____________ ____ ____
10.000µ 1 kHz 3 ____________ ____ ____
