PERFORMANCE TESTS
5-8
SR715/720 PERFORMANCE TEST RECORD
Serial # __________________ Date _________________
Tested by _________________________
Equipment used _____________________________________________________________________
____________________________________________________________________________________
Functional Tests
Pass Fail
Front Panel Test ____ ____
Self Test ____ ____
Output Voltage ____ ____
Resistance Test 24.9 Ω ____ ____
400 Ω ____ ____
6.4 kΩ ____ ____
100 kΩ ____ ____
Capacitance Test ____ ____
Frequency Accuracy
Test Frequency Minimum Actual Maximum
100 Hz 99.99 Hz ________ 100.01 Hz
120 Hz 119.99 Hz ________ 120.01 Hz
1 kHz 999.90 Hz ________ 1000.1 Hz
10 kHz 9999.0 Hz ________ 10001.0 Hz
100 kHz * 99990.0 Hz ________ 100010.0 Hz
Amplitude Accuracy
Amplitude Frequency Minimum Actual Maximum
1.0 Vrms 1 kHz 0.98 Vrms ________ 1.02 Vrms
1.0 Vrms 100 Hz 0.98 Vrms ________ 1.02 Vrms
1.0 Vrms 120 Hz 0.98 Vrms ________ 1.02 Vrms
1.0 Vrms 10 kHz 0.98 Vrms ________ 1.02 Vrms
1.0 Vrms 100 kHz * 0.98 Vrms ________ 1.02 Vrms
0.25 Vrms 1 kHz 0.245 Vrms ________ 0.255 Vrms
0.1 Vrms 1 kHz 0.098 Vrms ________ 0.102 Vrms
Internal Bias 1.96 VDC ________ 2.04 VDC
To Next Page
