OM600 ENGINE MECHANICAL 1B3-135
38 ± 0.2mm
or 37.6 ± 0.2mm
5. Insert the valve (1) into the valve guide according to marking
and measure amount by which the valve arrears ‘a’.
Arrears ‘a’ 0.1 - 0.7mm
6. Measure camshaft cam basic circle diameter (w).
Diameter ‘w’
7. Measure distance ‘z’ (cylinder head cover parting surface
- valve stem).
