1B3-142 OM600 ENGINE MECHANICAL
4. Install the camshaft bearing caps according to markings(1,
2, 3 etc.).
7. Remove the camshaft bearing cap.
8. Pull off the camshaft.
Notice
Be careful not to miss front locking washer.
9. Pull out the locking washer.
Notice
Check the condition of locking washer and replace if
necessary.
Installation Procedure
1. Insert the locking washer.
2. Check the valve tappet and ensure that tappet moves
smoothly.
3. Coat the camshaft with oil and install the camshaft onto the
cylinder head so that the TDC marking (arrow) is positioned
upward vertically.
To Next Page
