OM600 ENGINE MECHANICAL 1B3-89
14. Measure crankshaft bearing journal diameter (F).
Notice
When measured in A and B, the runout should not exceed
0.010mm.
8. Thoroughly clean the oil gallery.
9. Select a proper new bearing shells with reference to table.
10. Coat the new bearing shells with oil and insert into the
crankcase and into the crankshaft bearing caps.
Notice
Do not mix up upper and lower crankshaft bearing shells.
11. Install the bearing caps according to marking and tighten
the 12-sided stretch bolts.
Tightening Torque 35 - 40 Nm
Notice
No. 1 is vibration damper side.
12. Measure crankshaft bearing diameters (E).
Extension 366 589 00 21 05
13. Measure at 3 points (A, B and C) and if the average value
of B and C is less than A’ s value, the average value of B
and C is the mean value and if more than A’ s value, A’ s
value is the mean value.
To Next Page
