Table 8- 3 SR8000 Series System Parameters
Parameter
SR8000 Series 3D Camera
Model
SR8020
SR8060
Reference Distance(CD)
23mm
60mm
Z axis Height(F.S.)
5.2mm
18mm
X axis Width
14.5mm
31mm
Light Source Wavelength
405nm
405nm
Laser Class
2M
2M
Laser Output Power
10mW
10mW
Linearity of Z axis Height
±0.02% of F.S.
±0.02% of F.S.
Repeatability of Z axis Height
0.1um
0.2um
Repeatability of X axis Height
1.5um
5um
Profile Data Interval of X axis Height
5um
12um
Profile Pixel Number of X axis Height
3200
3200
Sampling Frequency (Hz)
(Trigger Frequency)
3200~67000
I/O Terminal
8 x Programmable Inputs, 8 x Programmable Outputs
Encoder Input
NPN/PNP open collector output, differential line driver output are all supported.
Communication Interface
1 x RS-232, 1 x 100Base-TX/1000Base-T
Operation Ambient Temperature
0～50
o
C
Storage Temperature
-20～70
o
C
Operation Ambient Humidity
35%～85% RH (No condensation)
ESD Protection
Contact Discharge: 4kV, Air Discharge: 8kV,
Conforming with the IEC61000-4-2 Standard
EFT Protection
Power supply port: 2kV/5kHz or 2kV/100kHz, Signal port: 1kV/5kHz or 1kV/100kHz,
Conforming with the IEC61000-4-4 Standard
Impact Resistance
15Gs/6ms; Conforming with the IEC 68-2-27 Ea Standard
Vibration Resistance
10 to 100 Hz double amplitude 1.5 mm; 3 hours in X, Y and Z directions;
Conforming with the IEC 68-2-6 Fc Standard
Protection Structure
IP67, Conforming with the IEC60529 Standard
Dimension (mm)
125.5x74x55
123.5x84x55
Mass (g)
650
630
Camera cable specification
SCB-HCAM-HB1-3m
、
SCB-HCAM-HB1-10m
