DocID15687 Rev 5 7/29
PM0059 Flash memory interface
28
2.3 Flash memory
The Flash memory has the following main features:
• Capacity up to 1 Mbyte
• 128 bits wide data read
• Byte, half-word, word and double word write
• Sector and mass erase
• Memory organization
The Flash memory is organized as follows:
– Main memory block containing 4 sectors of 16 Kbytes, 1 sector of 64 Kbytes, and
7 sectors of 128 Kbytes
– System memory used to boot the device in System memory boot mode.
This area is reserved for STMicroelectronics and contains the bootloader which is
used to reprogram the Flash memory through one of the following interfaces:
USART1, USART3, CAN2, USB OTG FS in Device mode (DFU: device firmware
upgrade). The bootloader is programmed by ST when the device is manufactured,
and protected against spurious write/erase operations.
– 512 OTP (one-time programmable) bytes for user data
The OTP area contains 16 additional bytes used to lock the corresponding OTP
data block.
– Option bytes: read and write protections, BOR level, watchdog software/hardware
and reset when the device is in Standby or Stop mode.
• Low power modes (for details refer to the Power control (PWR) section of the reference
manual)
Table 2. Flash module organization
Block Name Block base addresses Size
Main memory
Sector 0 0x0800 0000 - 0x0800 3FFF 16 Kbyte
Sector 1 0x0800 4000 - 0x0800 7FFF 16 Kbyte
Sector 2 0x0800 8000 - 0x0800 BFFF 16 Kbyte
Sector 3 0x0800 C000 - 0x0800 FFFF 16 Kbyte
Sector 4 0x0801 0000 - 0x0801 FFFF 64 Kbyte
Sector 5 0x0802 0000 - 0x0803 FFFF 128 Kbyte
Sector 6 0x0804 0000 - 0x0805 FFFF 128 Kbyte
.
.
.
.
.
.
.
.
.
Sector 11 0x080E 0000 - 0x080F FFFF 128 Kbyte
System memory 0x1FFF 0000 - 0x1FFF 77FF 30 Kbyte
OTP area 0x1FFF 7800 - 0x1FFF 7A0F 528 bytes
Option bytes 0x1FFF C000 - 0x1FFF C00F 16 bytes
