STM32F746G-DISCO IO assignment UM1907

42/49 DocID027942 Rev 3

H1 PH1/OSC_OUT RCC_OSC_OUT -

H2 PF3 FMC_A3 -

H3 PI14 LTDC_CLK -

H4 PH4 USB_OTG_HS_ULPI_NXT -

H5 VDD - -

H6 VSS - -

H10 VSS - -

H11 VDD - -

H12 PJ8 LTDC_G1 -

H13 PJ10 LTDC_G3 -

H14 PG8 FMC_SDCLK -

H15 PC6 ARDUINO TX/D1 -

J1 NRST - Hardware RESET

J2 PF4 FMC_A4 -

J3 PH5 FMC_SDNWE -

J4 PH3 FMC_SDNE0 -

J5 VDD - -

J6 VSS - -

J10 VSS - -

J11 VDD - -

J12 PJ7 LTDC_G0 -

J13 PJ9 LTDC_G2 -

J14 PG7 ARDUINO D4 -

J15 PG6 ARDUINO D2 -

K1 PF7 ARDUINO A4 -

K2 PF6 ARDUINO A5 -

K3 PF5 FMC_A5 -

K4 PH2 NC2 -

K5 VDD - -

K6 VSS - -

K7 VSS - -

K8 VSS - -

K9 VSS - -

K10 VSS - -

K11 VDD - -

Table 10. STM32F746G-DISCO IO assignment (continued)

Pin No. Pin Name Signal or Label Comment
