DocID027942 Rev 3 43/49

UM1907 STM32F746G-DISCO IO assignment

K12 PJ6 LTDC_R7 -

K13 PD15 FMC_D1_DA1 -

K14 PB13 USB_OTG_HS_ULPI_D6 -

K15 PD10 FMC_D15_DA15 -

L1 PF10 ARDUINO A1 -

L2 PF9 ARDUINO A2 -

L3 PF8 ARDUINO A3 -

L4 PC3 FMC_SDCKE0 -

L5 BYPASS_REG - Connected to PD R20

L6 VSS - -

L7 VDD - -

L8 VDD - -

L9 VDD - -

L10 VDD - -

L11 VCAP_1 - Connected to C47

L12 PD14 FMC_D0_DA0 -

L13 PB12 USB_OTG_HS_ULPI_D5 -

L14 PD9 FMC_D14_DA14 -

L15 PD8 FMC_D13_DA13 -

M1 VSSA - Connected to GND

M2 PC0 USB_OTG_HS_ULPI_STP -

M3 PC1 ETH_MDC -

M4 PC2 USB_OTG_HS_ULPI_DIR -

M5 PB2/BOOT1 QUADSPI_CLK -

M6 PF12 FMC_A6 -

M7 PG1 FMC_A11 -

M8 PF15 FMC_A9 -

M9 PJ4 LTDC_R5 -

M10 PD12 QUADSPI_BK1_IO1 -

M11 PD13 QUADSPI_BK1_IO3 -

M12 PG3 EXT_RST -

M13 PG2 RMII_RXER -

M14 PJ5 LTDC_R6 -

M15 PH12 DCMI_D3 -

N1 VREF- - Connected to GND

Table 10. STM32F746G-DISCO IO assignment (continued)

Pin No. Pin Name Signal or Label Comment
