8
Reference design
8.1
Description
The STM32H725G-DK Discovery board and the NUCLEO-H723ZG and NUCLEO-H725ZG Nucleo boards are
good references that can be used as a basis for a specific application development.
Details of these boards are available on
www
.st.com
website.
AN5419
Reference design
AN5419
-
Rev 2
page 33/50
32
34
