Stabila TECH 196 DL Series User Manual

2
en
Contents
Section Page
• 1. Intended use 3
• 2. Safety information 3
• 3. Description of the unit 4
• 3.1 Components of the unit 4
• 3.2 Buttons 5
• 3.3 Display elements 5
• 4. Commissioning 6
• 4.1 Inserting/replacing batteries 6
• 4.2 Switching the unit on 6
• 5. Functions 7
• 5.1 Visual guidance 7
• 5.2 Acoustic guidance 8
• 5.3 Setting the unit of measurement 9
• 5.4 Automatic display inversion 13
• 5.5 Locking the measurement with HOLD 13
• 5.6 Freely selectable zero position REF 14
• 5.7 Lighting 15
• 5.8 Keylock 15
• 5.9 Automatic switch-off time: Auto OFF 15
• 6. Tilt function 16
• 7. Checking the measuring tool
17
• 7.1 Accuracy check 17
• 7.2 Calibration 18
• 8. Technical data 19

Stabila TECH 196 DL Series Specifications

General

Brand	Stabila
Model	TECH 196 DL Series
Category	Measuring Instruments
Language	English
