Stabila TECH 196 DL Series - Buttons on the Unit; Display Elements Explained

5
en
3.3 Display elements
Elements for visual guidance
Units of measurement: °, %, mm/m, in/ft
Acoustic guidance: activated
Battery low - see chapter 5.1
Roof pitch guidance: activated
Keylock: activated
Lock measurements: activated
Reference: activated
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
3.2 Buttons
Acoustic guidance
Units of measurement: °, %, mm/m, in/ft,
roof pitch guidance
Sensitivity
Keylock
HOLD – lock measurements
Reference – freely selectable zero position
On/Off
Display lighting
