3. Components and Functions
3.5 Strip Loading plate Component
[Fig 3.4] Strip Loading plate Component and Name
3.6 Changing direction Strip Loading plate
UroMeter120 is designed both right hand and left hand users. Push
the tray right side, change the direction, and put it from left to right.
[Fig 3.5] Pull out Tray
Left Sensor Right Sensor
Sensor Filter Tray
▶
