3. Components and Functions
3. Components and Functions
3.1 Keyboard
Keyboard consists of 16 keypads. It is used to input data or set up
each function.
[Fig 3.1] Key Board
1) ENT Key
ENT Key is used to initiate testing or select a mode at each step.
2) ESC Key
ESC Key is used to terminate testing or escape from each step. At
Standby mode, press ESC key twice, then System Control Mode
will be shown.
3) ◀▶▲and ▼ Key (Direction Keys)
Direction Keys are used to move to the left, right, up and down,
respectively in each menu or to increase or decrease numbers in
stead of Numeric Keys.
4) 0~9 (Numeric) Keys
Numeric Keys are used to select a mode at each step or input data
such as patient’s ID, Lot number, etc.
