Stanley K1200 User Manual

16
Figure 14 - Room temperature probe
10. Control Tiemme
Waterford Stanley stoves may be equipped with Tiemme electronics, the Tiemme display is as shown below. To confirm if your
equipment is equipped with these electronics, please check the serial number of the equipment and refer to Table 3.
Tiemme Electronic Serial No. of equipment
K1200
≥ 01-21-00193
K1700
≥ 01-21-00243
K2300
≥ 01-21-00291
Table 3 - Serial No. with Tiemme electronic
10.1. Display
When connecting the equipment, the display indicates the “OFF” status of the stove, and can also indicate the chrono activation,
system errors, selected combustion power, selected ventilation power, current room temperature and selected room temperature
set-point.
In the Home Page by pressing the key:
• “P1” it’s possible to exit the menu/submenu;
• “P2” it’s possible to switch on the equipment, or, switch off the equipment. The same button allows the errors reset, by
pressing 3 seconds continuously, it also allows the activation of Chrono in the corresponding submenu;
• “P3” it’s possible to access the user menu 1, by pressing 3 seconds on the same button we can access the user menu 2 and
it also allows saving changes;
• “P4” it’s possible to enter the Combustion Power menu;
• “P5” it’s possible to enter the Information menu and also activate a Chrono time slot;
• “P6” it is possible to enter the Room Thermostat menu;
• “P3” + “P5” for 3 seconds it is possible to access the secondary information menu present in the service menu where it is
possible to check a set of variables.
