40
Figure 30 - Opening the lid
13.4. Filling the pellet reservoir
1 – Open the pellet reservoir lid at the top of the unit, as shown in Figure 30.
2 – Pour the pellets into the reservoir, as shown in Figure 31.
Figure 31 - Refilling the pellet reservoir
3 - Turn on the unit and close the lid, pressing it down as shown in Figure 30-a.
14. Installation and operation with the remote control (chrono-thermostat) – not included
in free standing units
The free-standing pellet fire units are produced with the command device (display). Alternatively, they can be used with a generic
remote-control unit (programmable thermostat).
Note: the remote control is usually accompanied by a manual. To use the remote control, the interface is already installed in the
appliance.
a) b)
c)
Figure 32 - Remote control (programmable thermostat) connection interface
