Stanley Pro MC521 User Manual

MC521 PRO Control Box
28 Document # 204066 REV D2 • www.stanleyaccesstechnologies.com • 1.800.7.ACCESS
Copyright 2015, Stanley Security Solutions. All rights reserved. Reproduction in whole
or in part without the express written permission of Stanley is prohibited.
10.21.2015
Attachment 8
Recommended Values for Different/Weights Types of Slide Door
Index Description Slide Doors
125 LB
Single Motor
Single Slide
350 LB
Single Motor
Bi-Part - LPH
100 LB
Single Motor
Bi-part
600 LB
Double Diamond
or Equiv.
Dura-Max
00 Open Speed 35 25 35 35 30
01 Close Speed 12 12 12 12 12
02 Check Speed 4 4 4 4 4
03 Open Check Length 35 35 35 40 35
04 Close Check Length 20 30 23 30 30
05 Reduced Open 1 1 1 50 50
06 Hold-open delay 15 15 15 15 15
07 Lock Logic
08 Open torque, percent of full torque 50 25 25 60 30
09 Close torque, percent of full torque 25 25 20 7 20
10 Check torque, percent of full torque 25 25 30 7 20
11 Dura-Glide Funcon Switch Type
12 2S Operaon
13 Obstrucon Time 50 50 50 100 60
14 Open Acceleraon Slope 60 50 60 60 50
15 Open Braking Slope 54 54 54 54 48
16 Close Acceleraon Slope 20 20 20 20 20
17 Close Braking Slope 50 50 20 50 20
18 Delay Egress
19 Safety Logic
20 Hold Beam Type 00-Optex
01-Photo
Beam pro
00-Optex
01-Photo
Beam pro
00-Optex
01-Photo
Beam pro
00-Optex
01-Photo
Beam pro
00-Optex
01-Photo
Beam pro
21 Open Stop 6 6 6 6 4
28 Close Press Time 1 1 1 1 1
29 Open Check Boost 2 2 2 2 2
