MC521 PRO Control Box
10.21.2015
1.800.7.ACCESS • www.stanleyaccesstechnologies.com • Document # 204066 REV D2 29
Copyright 2015, Stanley Security Solutions. All rights reserved. Reproduction in whole
or in part without the express written permission of Stanley is prohibited.
Attachment 9
Fine Tuning Slide Doors
(Sheet 1 of 2)
Tuning the Stanley Automatic Door
Match your actual door to one from the list of doors described in the aachment. Start by installing these sengs.
Use the guide below to make adjustments to these sengs.
If the door:
OPENS TOO SLOWLY
If it is too slow
If it is too slow
Increase Open Speed. Maximum seng is 35
Increase Open Torque
Increase Open Acceleration
** Open Torque is also used to set the door open force.
** Open Speeds and Force must comply with UL and ANSI/BHMA 156.10 requirements.
HITS THE OPEN STOP
Increase Open Stop to 8 and Open Check Length to 45
Increase Open Brake unl there is good braking.
Increase or decrease Open Check Boost unl there is good moon
entering and in Open Check.
When the door braking and moon are under control, reduce the Open Check length as desired.
CLOSES TOO SLOWLY
If it is too slow
If it is too slow
Increase Close Speed to 16
Increase Close Torque
Increase Close Acceleration
**Close Torque is also used to set the door closing force. Close Speed and Close Force cannot exceed the
value specied by ANSI/BHMA 156.10.
