ENGLISH ENGLISH
2.2 PLACING SPECIFICATIONS
Rivet Type
2,4
[3/32´´]
3,2
[1/8´´]
4,0
[5/32´´]
4,3 4,8
[3/16´´]
5,0 6,0 7,0
Open End
   
Closed End
   
HR
  
SSD SSHR

(1)

(1)
Multi-Grip
  
TL
  
Pull-Thru

T-Rivet (Emhart)

(1)
Self-Plugger
  
Ultra-Grip (UG) (NPR)

Avex®
  
Stavex®
  
Avinox®
  
Avibulb®
  
LSR/Bulbex®
 
T-Lok®
 
Avdel® SR
  
Interlock®

Monobolt®

(1)
Avseal® (STD)

(1)(2)

(1)(2)

(1)(2)

(1)(2)
Q Rivet
  
Klamp-Tite BAPK®

Klamp-Tite BAPKTR®

(1)
VGrip

 Is applicable for both XT1 and XT2 tool
(1) Non-standard nose piece required
 Is only applicable for XT1 tool
(2) Non-standard nose equipment required.
 Is only applicable for XT2 tool
For a full list of compatible nose equipment for each rivet type, together with assembly and maintenance
instructions, please refer to the ProSet Nose Equipment Manual 07900-09412
2.3 THE PACKAGE CONTENTS
• 1 ProSet® XT1 or XT2 blind rivet tool.
• 1 set Standard Nose Equipment & Nosepieces:
XT1: 2.4 [3/32´´], 3.2mm [1/8”] and 4.0m [5/32”]
XT2: 3.2mm [1/8”], 4.0m [5/32”] 4.8mm [3/16”]
• 1 Printed Instruction Manual – region dependent.
2.4 MAIN COMPONENTS LIST
Refer to gure 1 & 2 and the table below.
Item Part Number Description Qty
1
TRM00360 Standard nose equipment XT1 tool
1
TRM00361 Standard nose equipment XT2 tool
2 TP144-171 Suspension hook 1
3 TRM00227 Mandrel collector 1
4 07001-00405 Oil plug 1
5 07003-00194 Seal 1
6 76003-02008 Trigger 1
7 TRM00221 On/O valve 1
2.5 STANDARD NOSE EQUIPMENT
Refer to gure 2 and the table below.
Item
XT1 tool
Part Number
XT2 tool
Part Number
Description Qty
1a
PRN314 - Nose Piece - 2.4mm [3/32”]
1
- PRN614 Nose Piece - 4.8 mm [3/16”] (tted on XT2)
1b PRN414 PRN414 Nose Piece - 3.2 mm [1/8”] (tted on XT1) 1
1c PRN514 PRN514 Nose Piece - 4.0 mm [5/32”] 1
1d TP144-111 TP144-048 Nose housing 1
1e TP144-091 TP144-091 O-ring 1
1f DPN239-006 DPN275-001 Jaw guide 1
1g PRG402-8A 71210-15001 Jaws 1 Set
1h TP144-117 TP144-050 Jaw pusher 1
1i TP144-118 TP144-088 Urethane washer 1
1j TP144-119 TP144-081 Jaw pusher spring 1
1k TP144-120 TP143-052 Mandrel guide 1
1l TRM00167 TRM00165 Pulling head 1
1m TP144-113 TP144-051 Jaw guide lock 1
1n TP144-114 TP144-080 Jaw guide lock spring 1
1o DPN900-004 DPN900-002 O-ring 1
1p TRM00238 TRM00239 Nose Housing Nut 1
For additional nose equipment please refer to the ProSet® Nose Equipment Manual 07900-09412 or visit
www.stanleyengineeredfastening.com/resource-center/document-library
For a full list of tool accessories, please refer to the ProSet Accessories Manual 07900-09413.
