3-6-1. Compliant Paper Roll Specications
Paper thickness
65μmto85μm
Paper width
79.5 ± 0.5 mm
57.5 ± 0.5 mm
Note: Never change the paper width while the printer is in use.
External dimensions
• Roll diameter
Max.102mm
• Take up paper roll width
80
+0.5
mm / 58
+0.5
mm
Core inner and outer diameters
Inner diameter 12 ± 1 mm, externaldiameter 18 ± 1 mm
Printed surface
Outer edge of roll * You cannot use inner-wrapped paper rolls.
Note 1: Do not glue or tape the paper roll and shaft core together.
2: Do not fold the tail end of the paper.
3: For details on recommended thermal paper, see the following webpage.
http://www.starmicronics.com/support/
