Star Micronics TSP800 Series Technical Manual

– 17 –
1 32090050 GROUND PLATE D TMP8 1
2 33215020 BEARING TMP8 1 S
3 37461200 COVER A ASSY TMP8 1 WHITE
37461220 COVER A ASSY TMP8GRY 1 GRAY
4 30903010 CUTTER UNIT ORC-RSY120 1 S
5 33910300 PAPER GUIDE B TMP8 1
6 33910290 PAPER GUIDE A TMP8 1
7 37461020 PE DETECTOR COVER UNIT TMP8 1
8 37467010 PE DETECTOR UNIT TMP8 1 S
9 37463100 PLATEN UNIT TMP8 1 S
10 32020050 RELEASE PLATE TMP8 1
11 33102250 GEAR 24X0.7-55X0.5 TMP8 1 S
12 33102260 GEAR 40X0.5 TMP8 1 S
14 33400040 LOCK LEVER TMP8 1
15 37460200 HEAD HOLDER PLATE UNIT TMP8 1
16 04400001 OIL DAMPER 058E-F 1
17 31382010 SHAFT B TMP8 2
18 32020030 TENSION SHAFT PLATE TMP8 2
19 32047000 CASE STOPPER TMP8 1
20 32090020 GROUND PLATE A TMP8 2
21 32090040 GROUND PLATE C TMP8 1
22 33000001 FRAME TMP8 1
23 33301000 TENSION SHAFT TMP8 1
24 33400020 PUSH LEVER TMP8 2
25 37462000 PF MOTOR UNIT TMP8 1 S
26 33020530 NEAR-END DETECTOR COVER TMP8 1
27 37467300 NEAR-END DETECTOR ASSY TMP8 1 S
28 37460700 COVER OPEN LEVER UNIT TMP8 1 WHITE
37460710 COVER OPEN LEVER UNIT TMP8GRY 1 GRAY
29 37469000 HEAD UNIT TMP8 1 S
30 37461210 COVER B ASSY TMP8 1 WHITE
37461230 COVER B ASSY TMP8GRY 1 GRAY
31 32020060 LOCK PLATE TMP8 1
32 30531110 LOCK PLATE SPRING TMP8 1
33 33102240 GEAR 14X40X0.8 TMP8 1
41 00917504 SCREW TAT 1.7-5 PT 1 S
42 00820304 SCREW TR 2-3 2 S
43 01902028 SCREW TAT 2-4 3 S
44 00920603 SCREW TAT 2-6 PT 1 S
45 01902024 SCREW TAT 2-6 2 S
47 00630504 SCREW TR 3-5 1 S
48 00930609 SCREW TAT 3-6 CT 2 S
49 00930603 SCREW TAT 3-6 PT 1 S
50 01903061 SCREW TAT 3-6 PT-FL 6 S
51 00930803 SCREW TAT 3-8 PT 2 S
52 04020010 STOP RING SE2.0 1 S
53 04020015 STOP RING SE3.0 1 S
54 30531100 CLAMP SPRING TMP8 2
55 04991204 FASTENER T18S 3 S
56 09990717 FERRITE CORE BP53-19-12-8 1
57 82200010 COLLAR 822 1
58 30510420 SPRING E043-035-0164 1
59 30510520 SPRING E050-032-0141 2
60 30520600 SPRING C068-050-0065 1
61 30520700 SPRING C075-060-0300 1
62 30520710 SPRING C075-070-0238 2
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
3-2-2. Parts List
Printer Mechanism

Star Micronics TSP800 Series Specifications

General

Resolution	203 dpi
Paper Type	Thermal paper
Print Width	72 mm
Interface	USB, Ethernet, Serial, Parallel
Emulation	ESC/POS
Operating System Compatibility	Windows, Linux, Mac OS
