CHAPTER 1
PARTS REPLACEMENT
This chapter explains disassembly and reassembly of the printer. Note the following precautions during
disassembly and reassembly.
1. Disconnect the printer power cord plug from the wall outlet before servicing it.
2. Assembly is the reverse of disassembly unless otherwise specified.
3. After reassembly, coat the screw heads with locking sealant.
4. Lubrication information is not provided in this chapter. Refer to item 2 of chapter 2.
5. The printer has no adjustable parts.
1. Lower Case Unit ....................................................................................................3
2. Upper Case Unit ....................................................................................................3
3. Board Chassis Unit ...............................................................................................4
4. Main Logic Board ..................................................................................................4
5. Platen Unit..............................................................................................................5
6. Paper Feed Motor ..................................................................................................5
1
