StarTech.com PM1115U2 User Manual

9
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Connecting a Printer
1. Connect a USB 2.0 Cable (not included) to the USB-A Port
on the Print Server and the other end to a USB-A port on a
Printer.
2. Connect the Universal Power Adapter to the Power Jack
on the back of the Print Server and to an AC Electrical
Outlet. The Power LED will illuminate green to indicate that
the Print Server is turned on and correctly connected to the
Network.
Software Installation
Installing the Print Server Setup Software
1. Connect an CAT5e/6 Cable to the RJ45 Port on the Print
Server and to a Router or Network Device.
2. On the computer that’s connected to the same router or
network, download the drivers from www.startech.com/
PM1115U2.
3. Click on the Support tab, under Drivers and select the
appropriate driver package.
4. Once you have download and unzipped the driver. Click on
the Installation Guide PDF and follow the instructions.

StarTech.com PM1115U2 Specifications

General

Internal	No
Power LED	Yes
Product color	Black
LED indicators	Activity, Link, Power
Chipset	EST2862B
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Supported network protocols	LPR
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	0
Ethernet LAN (RJ-45) ports	1
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows RT, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Input current	0.3 A
Cables included	LAN (RJ-45)
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	215 mm
Package width	149 mm
Package height	54 mm
Package weight	326 g
Sustainability certificates	RoHS
Certification	CE, FCC

Weight and Dimensions

Depth	55 mm
Width	52 mm
Height	25 mm
Weight	60 g
