StarTech.com PM1115U2 User Manual

8
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Hardware Installation
Installing the Power Adapter Clip
1. Remove the Power Adapter from the box.
2. Locate the Power Clip specic to your region (e.g. U.S.).
3. Align the Power Clip with the Contact Prongs on the Power
Adapter so that the two Tabs on the Power Clip are aligned
with the cutouts on the Power Adapter.
4. Rotate the Power Clip clockwise until you hear an audible
click indicating that the Power Clip is properly attached to
the Power Adapter.
Removing the Power Adapter Clip.
1. Push and hold the Power Clip Release button on the Power
Adapter just below the Power Clip.
2. While holding the Power Clip Release button rotate the
Power Clip counter-clockwise until the Power Clip releases
from the Power Adapter.
3. Gently pull the Power Clip away from the Power Adapter.

StarTech.com PM1115U2 Specifications

General

Internal	No
Power LED	Yes
Product color	Black
LED indicators	Activity, Link, Power
Chipset	EST2862B
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Supported network protocols	LPR
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	0
Ethernet LAN (RJ-45) ports	1
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows RT, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Input current	0.3 A
Cables included	LAN (RJ-45)
Storage temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	215 mm
Package width	149 mm
Package height	54 mm
Package weight	326 g
Sustainability certificates	RoHS
Certification	CE, FCC

Weight and Dimensions

Depth	55 mm
Width	52 mm
Height	25 mm
Weight	60 g
