Status Pro – T430 User Guide
3. RC310 Remote Control
The RC310 is a remote control device with several functions.
Its primary use is to enable operation of the T430 without physically touching the laser
unit, all functions of the T430 are possible using the RC310 except for turning on and off.
The RC310 can also be used for showing the measurement
value of a R310 reveiver if the sensor is at a distance from the
Laser. The measurement value from the R280 or R290 is trans-
mitted to the RC310 over infrared.
It is strongly recommended to work with the Launchpad soft-
ware instead of the RC310 Remote Control.
RC 310 REMOTE CONTROL
2.6 Control via Infrared
The T430 can receive commands via infrared and not
only by bluetooth. These signals can be sent using either
the RC310 Remote Control (see Chapt. 3) or using the
Receivers R280 or R290.
It is important that the infrared receiver can receive the
signals and consequently process them further.
When an R280 or R290 sends a command to the laser, movement in the X or Y axis
depending on which has been selected, will infrared be activated. The laser moves within
the axis until a value of 0,00 is reached. As long as infrared is active the laser will be cor-
rected to 0,00 should the value drift.
