SIGNALS AND SPECIAL FEATURES
4. Signals and Special
Features
4.1 Power-LED
4.2 Battery-LED (green)
4.3 Battery-LED (red)
4.4 Levelling-LED for X-/Phi-axis
Permanently lit Laser is turned on, no errors•
5Hz-Flash
Error •
(Power problem, boot sector error, end of position
reached ...)
Power-On- / Power-Off-Sequence•
Permanently lit Supply voltage sufficient•
5Hz-Flash Power-On- / Power-Off-Sequence•
1Hz-Flash Supply voltage below minimum threshold•
Permanently lit Axis is in levelling mode•
5Hz-Flash
Power-On- / Power-Off-Sequence•
Levelling not possible, outside of measurement range•
1Hz-Flash Temperature drift too large (usually during warm-up) – WAIT•
5Hz-Flash Power-On- / Power-Off-Sequence•
