Status Pro – T430 User Guide
5. Technical Details
General
System: Digital, 2. Generation
Self-calibration: Bodyturn-System
Installation: SAL-System (self aligning system)
Environment compensation: Temperature, vibration
Interference rejection: Modulation of the lasers
Dimension: 100 x 126 x 96 mm
Connection: Bluetooth (Class 2), Infrared
Laser classification: Class 2a, visible
Measurement range: 0 – 50 m
Usable rotation plane: 360°
Power supply: Li-Ion accumulator (changeable)
Weight: 802g
Accuracies of the T430 (optimal conditions)
Straightness measurement: <((0,5 µm)² + (0,75 µm/m)²)
Flatness measurement: <((10 µm)²“ + (1,2 µm/m)²)
Flatness with ProLevel SW: <((4 µm)² + (1,5 µm/m)²)
Perpendicularity with MRB
System: <((1,2 µm)² + (4,5 µm/m)²)
(modulated rotating beam)
Levelling: <((5 µm)² + (1,5 µm/m)²) (calibrated)
TECHNICAL DATA
0,5Hz-Flash
Levelling: Y-axis is more than 1000 steps away from calibrated•
levelling value
Levelling: Temperature gradient still too high•
Levelling demand (after power on): Device in warming phase •
(1 min)
Levelling demand (after power off): Warning for unreliable •
values
2-Sensor-Control:•
Y-axis is more than 5 steps away from target position
